HHC Series
Hydrothermal Synthesis Reactor
-
Stainless steel 304 material,
-
Corrosion-resistant and high-pressure resistant,
-
Structurally sound,
-
Explosion-proof and safe
Overview
A hydrothermal synthesis reactor is a device specifically designed for conducting chemical reactions under high-temperature, high-pressure aqueous conditions. It utilizes strong acids, strong bases, or pure water in a sealed environment to promote the dissolution or transformation of substances that are insoluble or sparingly soluble at room temperature and pressure, thus achieving efficient digestion of samples.
In addition to its digestion capabilities, hydrothermal reactors are widely used in the field of crystal growth. By precisely controlling the temperature gradient and supersaturation conditions of the solution, they can induce the formation of ordered nanostructures or single crystals from inorganic or organic compounds.
Compact in size, easy to operate, cost-effective, and durable, hydrothermal reactors play a role in small-scale synthesis in laboratory settings. They also find important applications in various scientific research fields such as petrochemical engineering, biomedical sciences, materials science, geochemistry, environmental science, food science, and commodity inspection. They are indispensable experimental equipment for higher education institutions and research institutions.
Features
-
The structure is reasonable, with no leakage of harmful substances, reducing pollution and ensuring safety.
-
Standard 304 stainless steel material with PTFE lining, corrosion-resistant, and able to withstand high temperatures and pressures, up to 300℃ and 3MPa.
-
The reactor body has a simple structure, making the disassembly of the hydrothermal reactor convenient and improving work efficiency.
-
Explosion-proof device: overpressure rupture, automatic pressure release, safe and reliable.
-
Customizable according to customer requirements.
Typical Applications
• Can be used for sample preparation in atomic absorption spectroscopy and plasma emission analysis.
• Suitable for small-scale synthesis reactions.
• Utilizes a high-temperature, high-pressure sealed environment with strong acids or alkalis inside the vessel to rapidly dissolve difficult-to-dissolve substances.
• Assists in sample digestion for the determination of trace elements and microelements in chemical analysis methods such as gas chromatography, liquid chromatography, plasma mass spectrometry, atomic absorption, and atomic fluorescence.
• Applicable for heavy metal determinations such as lead, copper, cadmium, zinc, calcium, manganese, iron, mercury, etc.
• Can be used as a high-pressure, corrosion-resistant, high-purity reaction vessel for applications like organic synthesis, hydrothermal synthesis, crystal growth, or sample digestion and extraction.
• Effective in sample preparation for digesting heavy metals, pesticide residues, food, sludge, rare earths, aquatic products, and organic substances.
The hydrothermal synthesis reactor is also a sealed container capable of dissolving hard-to-dissolve substances. It can be used for sample preparation in atomic absorption spectroscopy and plasma emission analysis, small-scale synthesis reactions, and utilizing the high-temperature, high-pressure sealed environment with strong acids or alkalis inside the vessel for rapid digestion of difficult-to-dissolve substances.
Model | HHC-25 | HHC-50 | HHC-100 | HHC-200 | HHC-250 | HHC-500 |
|---|---|---|---|---|---|---|
Optional | Lining: PPL, stainless steel | Lining: PPL, stainless steel | Lining: PPL, stainless steel | Lining: PPL, stainless steel | Lining: PPL, stainless steel | Lining: PPL, stainless steel |
Optional | Material of kettle body: 316L material, Hastelloy alloy | Material of kettle body: 316L material, Hastelloy alloy | Material of kettle body: 316L material, Hastelloy alloy | Material of kettle body: 316L material, Hastelloy alloy | Material of kettle body: 316L material, Hastelloy alloy | Material of kettle body: 316L material, Hastelloy alloy |
Optional | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe | High pressure needle valve, pressure gauge, temperature measuring hole, explosion-proof device, liquid collection pipe |
Operating Pressure(MPa) | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
Operate temperature(℃) | ≤200 | ≤200 | ≤200 | ≤200 | ≤200 | ≤200 |
External material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
Sealing structure | External: Mechanical Thread | External: Mechanical Thread | External: Mechanical Thread | External: Mechanical Thread | External: Mechanical Thread | External: Mechanical Thread |
Sealing structure | Internally: PTFE | Internally: PTFE | Internally: PTFE | Internally: PTFE | Internally: PTFE | Internally: PTFE |
Internal material | Teflon | Teflon | Teflon | Teflon | Teflon | Teflon |
Weight(Kg) | 1 | 2 | 3 | 7 | 9 | 13 |
Volume(ml) | 25 | 50 | 100 | 200 | 250 | 500 |
